Simply place the reference object on the object to be digitized and create a new project in the Flatify app. Then take a photo with the special Flatify camera.
Review the Image taken and select the correct reference object dimensions. Also select all the edges of the reference object. The more accurate the selection the better the results.
Finally check the distorted image and if you are happy with your result simply export it as Image file.
Another option is to trace the CAD bounds of the actual object. This saves the need for an CAD program on an computer. There are some limitations, for example it is currently not possible to draw round shapes.
No expensive equipment needed
Company phone can be reused
Saving a CAD program
One Photo - All Dimensions
No laser, measuring tape, ... necessary
Simple reference object
No matter what shape
Round, square or 20 corners
Even cutouts are no problem
Direct .DXF creation in the app
Simple Shapes: Directly in Flatify
Complex shapes: CAD program
Flatify App
Measurement of 2D objects and forms made easy.
